Lightning Arrestor

Lightning Arrestor

Features

  • Differential and Common-mode lightning/surge protection
  • 9.4V version for Ringline installations
  • 24V version for Industry standard power supply
  • Other voltages available upon request
  • Convenient G or H rail mounting

Operation

When a high voltage transient appears across the fieldbus lines the TVS diode turns on very quickly (in nanoseconds) and limits voltage seen by control cards to the nominal clamp voltage. The gas discharge tube may take up to 5us to turn on and during this time the TVS diode dissipates a high power pulse. Once the gas discharge tube turns on it clamps voltage across the lines to between 20-70V and steers the high current transient back to the field. The gas discharge tube is rated to handle very high current levels – up to 20kA for 20us. After the transient has expired the gas tube returns to its high impedance state (>10Gohm from each line to earth).

Specification

Nominal Differential Working Voltage
F903 : 9.4VDC (Ringline)
F903_24D : 24VDC
Nominal Differential Breakdown Voltage
F903 : 11VDC (1mA)
F903_24D : 30VDC (1mA)
Nominal Differential Clamp Voltage
F903 : 24VDC
F903_24D : 66VDC
Common Mode Impulse Current
20kA (8/20us pulse)
Operating Temperature Range
-30 to +75 deg C
Dimensions
71mm (L) x 50mm (W) x 35mm(H)*
Height is from top of ‘H’ rail

Ordering Information

Select product(s) for project list, then add to list.

Product name Product number
9.4VDC (Ringline) Lightning Arrestor F903
24VDC Lightning Arrestor F903_24D
